LIXiSE LXC6110E engine auto start generator control

Description

 LXC6110E series of power plant automation controller for the automation and monitoring system of a single diesel generator sets, use 32-bit microprocessor technology, achieve generator sets automatic boot/shutdown, the precision measurement of various parameters, alarm protection and three remote function.

The controller uses a large-screen LCD (240*128LCD)graphics display, all the important parameters can be displayed in page, save the page. At the same time can be displayed Chinese.English and other languages, all parameters can be adjusted from the controller panel, can also be a PC through a USB interface tweaks and RS485 or GPRS remote adjustment and monitoring.

Its structure is compact, simple wiring, high reliability, automation control systems are widely used in all types of generator sets and fire pumps.

Product Performance

1)    The average load rate, by calculating the load rate, detect genset load operation, avoid overload operation.

2)    Custom boot interface, user can add your own contact information, company name, logo, slogan, etc.

3)    Installment payment service, through the password form to manage gensets.

4)    Maintenance remind, Accumulative total run time automatically, Timely remind maintenance.

5)    Big screen (240 * 128) LCD display, on a page can browse all the data, avoid frequent page breaks.

6)    Multi-language selection, Support Chinese, English, Russian and Spanish.

7)    USB connection, plug and play, convenient for debugging and application.

8)    200 fault records, detailed record 25 parameters of failure moment, easy to analyze the failure reasons.

9)    Real-time clock automatically timed training run, programmable 2 sets of training time.

10)    Collect and display mains overvoltage, under voltage, over frequency, low frequency, loss phase and anti-phase warning function.

11)    Level 2 different identities password, Plus a one-time temporary password, Safe and reliable.

Features of LIXiSE Controllers

1)    The first one in China have USB and RS232 standard controller interface , customers do not have to spend extra money and time to buy the interface adapter.

2)    The first one in China launch of the generator controller with black box records.This function can record genset failure instant data to provide data basis for repairs, remote fault analysis, resolve problems quickly.

3)    The first one in China use of technology to automatically adjust the contrast on the generator controller , this technology can automatically adjust the contrast according to the ambient temperature to achieve from -32 ° C ~ 65 ° C temperature range can be displayed properly.
